VW | Audi 2.0L TSI MK7 | Garrett Turbocharger STG1 485hp

Find A dealer



VW | Audi 2.0L TSI MK7 | Garrett Turbocharger STG1 485hp

Stage 1 Features:

• Direct-Fit Stage 1 Upgrade
• 485HP | 362kW (flywheel) power capability (on-vehicle results)
• 47mm compressor inducer, 60mm compressor exducer
• 50mm turbine inducer, 45mm turbine exducer
• GT2260S turbocharger
• Audi A3, S3, TT, TTS
• VW Golf Base, AllTrack, GTI and R
• Complete assembly with calibrated electric actuator and ancillary components for OE fitment
• +17% flow compared to IS38 turbo (stock Golf R)
• GTX Gen II compressor wheel aero
• Modern gasoline turbine wheel aerodynamics constructed of Mar-M alloy rated for up to 1050C
• Stainless steel turbine housing rated for up to 1050C
• Fully machined speed sensor port
• Latest generation of journal bearing rotor group
• 360-degree thrust bearing –reinforced for application

Stage 1 Part number: 898199-5001W Supports up to 485 HP (362kW)*

Turbocharger Data

PowerMax PN Stage Power Model Comp Ind Comp Exd Turb ind Turb Exd
898199-5001W Stage 1 485HP | 362kW GT2260S 47mm 60mm 50mm 45mm



Application Data

Make Model Year Body & Trim Engine OEM Turbo
Audi TT 2014 + Base 2.0L L4 – Gas IS20
Audi TTS 2014 + Base 2.0L L4 – Gas IS38
Audi A3 2015 – 2018 Premium, Premium Plus, Prestige 2.0L L4 – Gas IS20
Audi A3 Quattro 2015 – 2018 Premium, Premium Plus, Prestige 2.0L L4 – Gas IS20
Audi S3 2015 – 2018 Premium, Plus, Prestige 2.0L L4 – Gas IS38
VW Golf 2015 S, SE, SEL, Launch Edition 2.0L L4 – Gas IS12
VW Golf GTI 2015 Autobahn, S, SE 2.0L L4 – Gas IS20
VW Golf R 2015 Base 2.0L L4 – Gas IS38
VW Golf 2016 Base, S, SE, SEL 2.0L L4 – Gas IS12
VW Golf GTI 2016 Autobahn, S, SE 2.0L L4 – Gas IS20
VW Golf R 2016 Base 2.0L L4 – Gas IS38
VW Golf 2017 S, Wolfsburg Edition 2.0L L4 – Gas IS12
VW Golf Alltrack 2017 S, SE, SEL 2.0L L4 – Gas IS12
VW Golf GTI 2017 Autobahn, S, SE 2.0L L4 – Gas IS20
VW Golf R 2017 Base 2.0L L4 – Gas IS38
Audi Golf 2018 S, SE, SEL 2.0L L4 – Gas IS12
Audi Golf Alltrack 2018 S, SE, SEL 2.0L L4 – Gas IS12
Audi Golf GTI 2018 Autobahn, S, SE 2.0L L4 – Gas IS20
Audi Golf R 2018 Base 2.0L L4 – Gas IS38
